Hot Line Tap Clamps LLC Series

For Aluminum, ACSR, and armor rod covered aluminum or ACSR conductor. For installation on energized conductor.

分类:
描述

描述

HOT LINE TAP CLAMPS

Description
For Aluminum, ACSR, and armor rod covered aluminum or ACSR conductor.
For installation on energized conductor.
Material
Body and Keeper – Aluminum Alloy
Eye bolt – Bronze alloy – Tin Plated
Eyestem – Bronze alloy, Forged or stainless steel
Spring (on eyestem) Stainless Steel

Models: LLC1520 E1030-AC LLC1530
Main Line(mm²) 16-70 10-120 16-185
Service Line (mm²) 16-50 10-70 16-95
Main Line(AWG) 6 sol-2/0 str al 8 sol-4/0 str al 6 sol- 400MCM al
Service Line (AWG) 6 sol-1/0 str al/cu 8 sol-2/0 str al/cu 6 sol-2/0 al/cu
Bolt No. 1 1 1
