Compression Splice JY(AAC)

OVERHEAD LINE SPLICES: AAC

Compression Splice

• For use with CRIMP tools only
• For aluminum, ACSR, compact, 5005, 6201 and ACAR partial tension (40% tension rating) conductor jumper splicing
• Aluminum alloy conductor recommendations include 5005 and ACAR having the same diameter as a given ACSR conductor shown below. In addition, compressed (compact) conductor sizes within the same decimal conductor range are recommended

Send Inquiry
Category:
Description

Description

Compression Splice JY(AAC)

Full-tension conventional compression splices

Material:

Body – Aluminum Alloy
Factory inhibited
